Rockwell Automation Publication 7000-UM202D-EN-P - May 2018 75

Power Component Definition and Maintenance Chapter 2

Figure 61 - Replacing the SGCT

Figure 62 - Replacing the SGCT (if SPS board is installed)

SGCT captive screws

Clamp head block

Disc Springs

Inside nut for loosening and

applying load to assembly

DO NOT ADJUST outside nut

Clamp head block

SPS board mounting

assembly captive screws

SGCT captive screws

Inside nut for

loosening and

applying load to

assembly

DO NOT ADJUST outside nut
