For reference, all major touch screen selections are described in the following. Selections
and entries are listed according to the following.
Main
Select
Setup
Scale
Test
Each selection is described with its typical application, along with the corresponding valid
range of entries, and a factory pre-programmed default value.
The Main screen provides a summary of filling performance and operational control of the
Model VF110-E. It includes the following displays and selections.
Start
Control used to start filling operations.
This selection is accessed from the Main screen.
Production Count
Displays the number of filled containers since Start was used. Display can be used as an
indicator of production.
This display is accessed from the Main screen.
CPM
Displays the computed Containers Per Minute as an indicator of production rate.
This display is accessed from the Main screen.
Stop
Control used to halt filling operations.
This selection is accessed from the Main screen.
Model VF110-E Touch Screen Control Panel Users Manual
19
AFI Publication 1910817 ● Issue: 1 ● August 2017
REFERENCE
Main
