The Scale screen provides access to selections and displays of the loadcell scale of the
Weigh Bucket.
The scale can be individually adjusted for specific operating conditions using these selec-
tions. Additionally, the scale can be re-calibrated to ensure accurate weighing.
The Scale screen is accessed from the Scale selection of the Main screen.
Raw Counts
Displays the input from the loadcell to verify that the loadcell is responding. If a weight is
present on the scale and Raw Counts doesn’t register, failure of the loadcell may be sus-
pected.
This selection is available from the Scale screen.
Scale Weight
Indicates weight present on the scale. This display can be used to verify correct scale oper-
ation or to indicate if calibration required.
This selection is available from the Scale screen.
Calibrated Weight
Provides entry of a standard mass value used during the calibration process.
Entry should correspond to the heaviest weight package of your application.
This selection is available from the Scale screen.
Factory Setting: 0.000
Valid Entries: 0.000-999.999
Start Cal.
Initiates the calibration process. A procedure to perform calibration is provided elsewhere in
this manual (see “Using the Controls”).
This selection is available from the Scale screen.
Step #1-#4
Completes the calibration sequence for each scale. Instructions appear on the screen to
complete each step.
This selection is available from the Scale screen.
Model VF110-E Touch Screen Control Panel Users Manual
29
AFI Publication 1910817 ● Issue: 1 ● August 2017
Scale
