Gate Control
Selects operation of a product gate control that is actuated to inhibit product flow during fill-
ing. The following types of control can be selected:
None – Gate does not operate.
With Fill – Gate closes during filling to inhibit product flow to achieve greater accuracy.
Dribble Fill – Gate closes during dribble stage to inhibit product flow to achieve greater
accuracy.
Selection is color-coded for a quick, visual indication of current setting. Selection appears
Green when selected as With Fill or Dribble Fill. Selection appears Red when selected as
None.
This selection is available from the Setup Bucket screen.
Factory Setting: None (Red)
Valid Entries: With Fill (Green), Dribble Fill (Green), None (Red)
Setup screen used to adjust how product resupply equipment operates with a Level Control
instrument.
This screen is accessed from the Setup selection on the Main screen.
On/Off Time
Provides a variable delay when the Level Control detects low product level and product
resupply equipment is actuated. Delay can be used to prevent over-filling of the hopper or to
keep infeed lines charged with product.
These selections are accessed from the Setup Level Control screen.
Factory Settings: 0.000
Valid Entries: 0.000-9.999
Model VF110-E Touch Screen Control Panel Users Manual
28
AFI Publication 1910817 ● Issue: 1 ● August 2017
Setup Level Control
