Screen that includes selections to operate the cascade vibrator, display weights, and oper-
ate the weigh bucket. Selections are described in the following.
This screen is available from the Test selection of the Main screen.
Vibration Rate
Selects speed rate for testing the cascade vibrator. This selection can be used to verify cor-
rect vibration operation as well as test different vibration rates affect on product flow.
This selection is available from the Test Cascade Vibrator screen.
Factory Setting: 0.00
Valid Entries: 0.000-100.000
Test Cascade Vib
Operates the cascade vibrator for testing, adjustment, etc. Pressing the selection turns the
vibrator on and off. Vibration operates at the rate selected from the Vibration Rate selection
(see previous).
This selection is available from the Test Cascade Vibrator screen.
Scale Weight
Displays the present value from the loadcell at the weigh bucket to identify and diagnose
problems, faults, or verify correct operation.
This selection is available from the Test Cascade Vibrator screen.
Tare
Re-zeroes the weigh bucket scale for testing, adjustment, etc.
This selection is available from the Test Cascade Vibrator screen.
Stepper Sensor Indicator
Displays when the Stepper Motor actuator is in the designated “Home” position. Indicator
appears Green when at “Home” and Red when not in home.
This selection is available from the Test Cascade Vibrator screen.
Model VF110-E Touch Screen Control Panel Users Manual
32
AFI Publication 1910817 ● Issue: 1 ● August 2017
Test Cascade
Vibrator
