Tolerance Weight
Defines the amount over and under the selected Target Weight that will be considered as
accept or reject.
For convenience, the controls calculate the corresponding high and low limit weight range
based on the target and tolerance settings.
This selection is available from the Setup Target Weight screen.
Factory Setting: 0.000
Valid Entries: 0.000-999.999
Setup screen used to determine weight, vibration, and minimum/maximum fill time settings,
as well as operation of a cascade vibrator (if included).
This selection is accessed from the Setup selection on the Main screen.
Bulk % of Target
Defines how much product is dispensed in the first stage fill as a percentage of final target
weight.
The entry will vary according to product type, bulk vibration rate, desired accuracy levels,
and production speeds. Greater percentages may result in faster production speeds but may
result in less accuracy.
This selection is accessed from the Setup Vibration screen.
Factory Setting: 0.000
Valid Entries: 50.00-100.00
Bulk Vibration
Selects the rate of vibration during the first, bulk stage fill. Generally, greater speeds will
result in more product, however greater speeds may yield less accuracy and greater preact
(in-flight) amounts.
This selection is accessed from the Setup Vibration screen.
Factory Setting: 0.00
Valid Entries: 5.00-100.00
Model VF110-E Touch Screen Control Panel Users Manual
24
AFI Publication 1910817 ● Issue: 1 ● August 2017
Setup Vibration
