Screen includes selections to select how weight signals are accepted from the loadcell of
the Weigh Bucket.
This selection is accessed from the Setup selection on the Main screen.
Bucket Tare Rate
This selection specifies how often the weigh bucket is re-zeroed before weight accepted to
accommodate the build-up of product. Entry is the number of fill cycles occurring between
taring, such as, an entry of 1 will tare the bucket for each cycle, 2, every other cycle, etc.
The entry will vary according to the type of product, overall accuracy levels, and desired
production rates.
This selection is available from the Setup Bucket screen.
Factory Setting: 0
Valid Entries: 1-30,000
Bucket Tare Delay
Provides a delay before the scale is re-zeroed. This delay can be used to allow the bucket
to stabilize before a tare occurs.
This selection is available from the Setup Bucket screen.
Factory Setting: 0.000
Valid Entries: 1.000-9.999
Bucket Open Time
Determines how long the bucket stays open to allow product to drop into the funnel. When
this period elapses, the bucket closes.
This selection is available from the Setup Bucket screen.
Factory Setting: 0.000
Valid Entries: 0.200-9.999
Model VF110-E Touch Screen Control Panel Users Manual
27
AFI Publication 1910817 ● Issue: 1 ● August 2017
Setup Bucket
