Test screen used to display signal from the Level Control instrument and test operation of
product request signal to product re-supply equipment.
This screen is available from the Test selection of the Main screen.
Hopper Low Level Indicator
Displays status from the Level Control detecting product level. Indicator appears Green
when sufficient product detected in the hopper or Red when at low level.
This selection is available on the Test Product Request screen.
Test Prod. Request
If the feeder is used with other equipment for product re-supply, this selection can be used
to turn the equipment on or off for testing, adjustment, etc.
!!! WARNING !!!
Operation of Product Infeed equipment may present a safety hazard. Take
appropriate precautions to protect operating personnel and other equipment
when testing this equipment.
Pressing the TEST PROD. REQUEST switch icon turns equipment on & off, accordingly.
This selection is available on the Test Product Request screen.
Factory Setting: Off
Valid Entries: On, Off
Test screen that allows inputs (I) and outputs (O) of the control panel to be displayed and
operated.
This screen is available from the Test selection of the Main screen.
Initiation Indicator
Displays the status of the actuated initiation signal (footswitch) to the VF110-E. Indicator
appears Green when signal is on or Red when off.
This selection is available from the Test Aux I/O screen.
Model VF110-E Touch Screen Control Panel Users Manual
34
AFI Publication 1910817 ● Issue: 1 ● August 2017
Test Product Request
Test Aux I/O
