E-Stop Indicator
Displays the signal from the Emergency Stop (E-Stop) switch on the control enclosure.
Indicator appears green when switched off and red when on.
This selection is available from the Test Aux I/O screen.
Test Vib Gate #1/#2
Selections used to operate (optional) gate cutoff components for testing, adjustment, etc.
Pressing the corresponding switch icon operates each Vib Gate, accordingly.
!!! WARNING !!!
Operation of a Vib Gate may present a safety hazard. Take appropriate precau-
tions to protect operating personnel and other equipment when testing this
equipment.
This selection is available from the Test Aux I/O screen.
Factory Setting: Off
Valid Entries: On, Off
Ok to Dump Signal
Operates the Ok to Dump signal to external equipment for testing. Pressing the switch icon
turns the signal on and off.
!!! IMPORTANT !!!
It may be necessary to refer to the wiring diagram accompanying this manual to locate
and identify the ok to Dump signal and/or connections
This selection is available from the Test Aux I/O screen.
Factory Setting: Off
Valid Entries: On, Off
End of Fill Signal
Operates the End Of Fill signal to external equipment for testing. Pressing the switch icon
turns the signal on and off.
!!! IMPORTANT !!!
It may be necessary to refer to the wiring diagram accompanying this manual to locate
and identify the End Of Fill signal and/or connections
This selection is available from the Test Aux I/O screen.
Factory Setting: Off
Valid Entries: On, Off
Model VF110-E Touch Screen Control Panel Users Manual
35
AFI Publication 1910817 ● Issue: 1 ● August 2017
