The Setup menus and screens provide access to selections and settings used to define
operation of the feeder. When selected, the following menus can be accessed and used:
Setup Target Weight
Setup Vibration
Setup Bucket
Setup Level Control
These menus, as well as selections available on each screen, are described in the follow-
ing. Setup screens are accessed from the Setup selection of the Main screen.
Provides access to setup selections that define a product name identification, target fill
weight and acceptable weight limits. Screen includes the following selections.
This selection is accessed from the Setup selection on the Main screen.
Product Name
This selection allows you to assign a alphanumeric code to the filling details of that particu-
lar program. Product Names can be used to associate Programs with specific product types,
containers, etc. Up to 20 characters (0-9 & A/a-Z/z) can be used.
This selection is available from the Setup Target Weight screen.
Factory Setting: (blank)
Valid Entries: 20 characters
Target Weight
Specifies the final, filled weight of product in the container.
This selection is available from the Setup Target Weight screen.
Factory Setting: 0.000
Valid Entries: 0.000-999.999
PreAct Weight
PreAct is the amount of product in-transit from the vibrating pan to the container. This set-
ting can be used to compensate for inflight product into calculations of the target weight.
This selection is accessed from each of the Setup Target Weight screen.
Factory Setting: 0.000
Valid Entries: 0.000-9.999
Model VF110-E Touch Screen Control Panel Users Manual
23
AFI Publication 1910817 ● Issue: 1 ● August 2017
Setup
Setup Target
Weight
