Model VF110-E Touch Screen Control Panel Users Manual
3
AFI Publication 1910817 ● Issue: 1 ● August 2017
Start Control used to start filling operations.
Production Count Displays the number of filled containers since Start
was used. Display can be used as an indicator of
production.
CPM Displays the computed Containers Per Minute as
an indicator of production rate.
Stop Control used to halt filling operations.
Bulk/Dribble Time Displays the time required to complete bulk and
dribble filling in the most recent fill cycle. These dis-
plays can be used in analysis of filling performance
and where adjustment is necessary.
Elapsed Time Displays the total time necessary to complete the
most recent fill cycle. As with the previous
(“Bulk/Dribble Time”), this display can be used used
in analysis of filling performance and where adjust-
ment is necessary.
Single Cycle Allows only a single container to be filled and is
useful for testing purposes.
Learn Mode The Learn Mode screen provides a method of
allowing the controls to optimize filling production
automatically without time consuming adjustment
and re-adjustment of setup entries and selections.
Menu Selection Allows access to the Select, Setup, Scale, Test, and
Stats screens during operation.
Status Messages
A message indicating the current operational state of the filler. The following messages may
appear. Weigh Bucket messages appear on the Main screen. System Messages appear at
the top of all screens.
No Control Power Wait For Initiation
System Ready: Press START Open Bucket
Bucket Not Ready Scale Alarm
Ready To Dump Stepper Alarm
Drop Product Max Fill Time Alarm
Release Initiation Bucket Not Close
