Test screens provide entries and displays useful in initial setup, testing, troubleshooting/ser-
vicing, and adjusting the feeder. These selections are described in the following.
Test screens and selections are accessed from the Test selection of the Main screen.
Screen that includes selections to operate vibrators, display weights, and operate the weigh
bucket. Selections are described in the following.
This screen is available from the Test selection of the Main screen.
Vibration Rate
Selects speed rate for testing the vibrator. This selection can be used to verify correct vibra-
tion operation as well as test different vibration rates affect on product flow.
This selection is available from the Test Vibrator screen.
Factory Setting: 0.00
Valid Entries: 0.000-100.000
Test Vib
Operates the vibrator for testing, adjustment, etc. Pressing the selection turns the vibrator
on and off. Vibration operates at the rate selected from the Vibration Rate selection (see
previous).
This selection is available from the Test Vibrator screen.
Scale Weight
Displays the present value from the loadcell at the weigh bucket to identify and diagnose
problems, faults, or verify correct operation.
This selection is available from the Test Vibrator screen.
Tare
Re-zeroes the weigh bucket scale for testing, adjustment, etc.
This selection is available from the Test Vibrator screen.
Model VF110-E Touch Screen Control Panel Users Manual
30
AFI Publication 1910817 ● Issue: 1 ● August 2017
Test
Test Vibrator
