ALLFILL VF110-E - Page 9

Gate Control
 Setup Level Control
Off Time
On Time
Scale
 Scale #1 Calibration
Raw Count display
Scale Weight display
Calibrated Weight
Start Cal
Step #1-#4
Test
 Test Vibrator
Vibration Rate
Test Vib
Scale Weight display
Tare
Stepper Sensor Indicator
Stepper Time
Open Bucket
Close Bucket
 Test Cascade Vibrator
Vibration Rate
Test Cascade Vib
Scale Weight display
Tare
Stepper Sensor Indicator
Stepper Time
Open Bucket
Close Bucket
 Test Product Request
Hopper Low Level Indicator
Test Prod. Request
 Test Aux I/O
Initiation Indicator
E-Stop Indicator
Test Vib. Gate #1
Test Vib. Gate #2
Ok to Dump Signal
End of Fill Signal
Model VF110-E Touch Screen Control Panel Users Manual
5
AFI Publication 1910817 ● Issue: 1 ● August 2017
