Chapter 13: Rapid Spanning Tree Protocol (RSTP)
172 Section I: Using the Menus Interface
The RSTP Advanced Port Configuration menu is shown in Figure 41.
Figure 42. RSTP Advanced Port Configuration Menu
4. Type E to select Edge Status.
The following prompt is displayed:
The following prompt is displayed:
Select port number to be changed>
Port number is in range from 1 to 9, 0 to set all ports
5. Enter the number of the port you want to change, or type 0 (zero) to
apply the settings to all ports on the switch.
The following prompt is displayed:
Set edge port for port n >(T/F)>
This parameter defines whether the port is functioning as an edge port.
The possible settings are True and False. For an explanation of this
parameter, refer to “Point-to-Point and Edge Ports” on page 159.
6. Enter T for True or F for False to change the Admin/OperEdge status.
7. Type P to select P-to-P Status.
AT-GS950/16 Local Management System
Rapid Spanning Tree Configuration -> RSTP Advanced Port Configuration
Port Trunk Link State Role Admin/OperEdge Admin/OperPtoP Migrat
---- ----- ---- ---------- --------- ----------------------------------
1 --- Down Forwarding Disabled False/False Auto/False Init.
2 --- Down Forwarding Disabled False/False Auto/False Init.
3 --- Down Forwarding Disabled False/False Auto/False Init.
4 --- Down Forwarding Disabled False/False Auto/False Init.
5 --- Down Forwarding Disabled False/False Auto/False Init.
6 --- Down Forwarding Disabled False/False Auto/False Init.
7 --- Down Forwarding Disabled False/False Auto/False Init.
8 --- Down Forwarding Disabled False/False Auto/False Init.
9 --- Down Forwarding Disabled False/False Auto/False Init.
10 --- Down Forwarding Disabled False/False Auto/False Init.
11 --- Down Forwarding Disabled False/False Auto/False Init.
12 --- Down Forwarding Disabled False/False Auto/False Init.
------------------------------- <COMMAND> ---------------------------------
[N]ext Page Set Port P-[t]o-P Status
[P]revious Page Restart Port [M]igration
Set Port [E]dge Status [Q]uit to previous menu
Command>
