AT-S79 Management Software User’s Guide
Section II: Using the Web Browser Interface 243
Pinging a Remote System
This procedure instructs the switch to ping a node on your network. This
procedure is useful in determining whether an active link exists between
the switch and another network device. Note the following before
performing the procedure:
 The switch where you are initiating the ping must have an IP address.
 The device you are pinging must be a member of the Default VLAN. In
other words, the port on the switch through which the node is
communicating with the switch must be an untagged or tagged
member of the Default VLAN.
To ping a network device, perform the following procedure:
1. From the Tools folder, select Ping.
The Ping Page is shown in Figure 66.
Figure 66. Ping Page
2. Configure the following parameters:
Destination IP Address
The IP address of the node you want to ping.
Timeout Value
Specifies the length of time in seconds the switch waits for a response
before assuming that a ping has failed. The default is 3 seconds.
