Section II: Using the Web Browser Interface 257

Chapter 24

Port Mirroring

This chapter contains the procedure for setting up port mirroring. Port

mirroring allows you to unobtrusively monitor the ingress and egress traffic

on a port by having the traffic copied to another port. This chapter contains

the following sections:

 “Configuring Port Mirroring” on page 258

 “Disabling Port Mirroring” on page 259

Note

For background information, refer to “Port Mirroring Overview” on

page 90.
