Displaying the RSTP Topology
To display the RSTP topology, perform the following procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
The Basic Switch Configuration Menu is shown in Figure 4 on page 34.
2. From the Basic Switch Configuration Menu, type S to select Rapid
Spanning Tree Configuration.
The Rapid Spanning Tree Configuration Menu is shown in Figure 40
on page 163.
3. From the Rapid Spanning Tree Configuration Menu, type I to select
Topology Information.
The Topology Information menu is shown in Figure 41.
Figure 43. Topology Information Menu
AT-GS950/16 Local Management System
Rapid Spanning Tree Configuration -> Designated Topology Information
PortTrunk Link Desig. Root Desig. Cost Desig. Bridge Desig. Port
--------- ---- --------------------------------------------------------
1 Up 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
2 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
3 Up 8000 000c46aa7fal 200000 8000 003084000000 00 03
4 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
5 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
6 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
7 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
8 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
9 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
10 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
11 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
12 Down 8000 00c08f1211bb 0 8000 00c08f1211bb 00 00
--------------------------------- <COMMAND> ---------------------------------
[N]ext Page [P]revious Page [Q]uit to previous menu
Command>
