0120028-J0 Rev F
44
7�3 Troubleshooting Converter Status LEDs
7�3�1 Card Alarms (All 4 LEDs)
LED State Individual Converter status Action
Green
Normal None
Blinking Green
Remote shutdown enabled on
whole module
Can be reset by toggling module/card Startup /
Shutdown button through the CXCI+ controller.
Shelf is not compatible with the
module
Ensure that the shelf is correct. (Note: Slots for the
eLimiter+ and LPS36 shelves are mechanically
identical and the modules can be interchanged.)
Module not seated properly Re-seat module
Yellow
Recoverable:
• Ambient temperature high
Resets automatically when ambient temperature
reduces to approximately 85°C or below.
Blinking Yellow
Input quality not OK Output is disabled if input voltage is not within the
range of 40-60Vdc.
OFF
Recoverable:
• No power
Check input wiring.
Non-recoverable:
• Main Input Fuse cut-off
Potential component failure. Replace with new
module.
Chasing Green Pattern
Non-recoverable:
• Group reset function not working
Hardware failure. Replace with new module.
Chasing Red/Green
Pattern
Locate feature enabled None
7�3� 2 Individual Channel Alarms
LED State Individual Converter Status Action
Green
Normal None
Blinking Green
Remote shutdown enabled on
individual channel/converter
Can be reset by toggling Startup / Shutdown button
through the CXCI+ controller.
Blinking Yellow
Recoverable:
• OCP/Overload
Ensure the load is within rated current.
Non-recoverable:
• Converter Input Fuse fail
Potential component failure. Replace with new module.
Red
Locked-State:
• OVP
OVP latch can only be reset by removing and
reinstalling the module or using the remote reset
function through the CXCI+ controller.
Non-recoverable:
• Converter Output Fuse fail
Failed fuses are not eld replaceable. Replace with new
module.
Blinking Red
Non-recoverable:
• Secondary sensory fail
Potential failure on current sensor. Replace with new
module.
