Hardware Setup
28
NHA80945 04/2017
Hardware Presentation
CANopen Fieldbus Modules
The following figure shows the VW3A3608 CANopen module with 2 RJ45 connectors:
The following figure shows the VW3A3618 CANopen module with a SubD9 connector:
The following figure shows the VW3A3628 CANopen module with an open style connector:
Firmware and Description File
Compatibility
The associated EDS file is named as the following example:
SEATV9x0_010102E.eds
The files are available on www.schneider-electric.com.
Item Description Comment
A Port A RJ45 connector
B Port B RJ45 connector
Item Description Comment
− − SubD9 connector
Item Description Comment
− − Open style connector
