Software Setup
NHA80945 04/2017 47
Summary
Device Status Summary
Operating State Power Stage Supply for
Separate Control Stage
Power Supplied to Motor Modification of Configuration
Parameters
1 - Not ready to
switch on
Not required No Yes
2 - Switch on
disabled
Not required No Yes
3 - Ready to
switch on
Not required No Yes
4 - Switched on
Required No Yes, return to 2 - Switch on
disabled operating state
5 - Operation
enabled
Required Yes No
6 - Quick stop
active
Required Yes, during fast stop No
7 - Fault reaction
active
Depends on error response
configuration
Depends on error
response configuration
−
8 - Fault
Not required No Yes
