5000KIT | 5000KIT AUTOMATION SET 83
SETTING UP OPERATING PARAMETERS
SETTING
INDICATION
SETTING DETAILS
Phototest
When the setting is enabled, an automatic test (Phototest) is run to check the operation of
the safety photodevices (photocells) connected to the ‘PH1’ and / or ‘PH2’ inputs.
The receiver of the photocells is connected to the ‘PH.T’ output (g. 20):
— Disabled.
Default setting.
— Enabled for opening and closing photocells. In the beginning of the closing and
opening, a test is run to check the photocells connected to the ‘PH1’ and ‘PH2’ inputs
respectively.
— Enabled for closing photocells. In the beginning of the closing, a test is run to check the
photocells connected to the ‘PH1’ input.
— Enabled for opening photocells. In the beginning of the opening, a test is run to check
the photocells connected to the ‘PH2’ input.
Gate type
— Single-leaf gate.
For a single-leaf gate, the drive is connected to the X2 connector (g. 18).
— Double-leaf gate.
Default setting.
Electric lock
When the setting is enabled, the ‘X10’ connector outputs are activated
(g. 18, tab. 11).
The connection diagram is selected, depending on the type of the electric lock
(g. 21 or g. 22):
— Disabled.
Default setting.
— Enabled.
As the leaf where the electric lock is installed (for a double-leaf gate, it is the leaf that opens
rst) starts opening, a short reversal occurs towards the closing direction (when the gate is
fully closed, no reversal occurs in the AM series drive) and the ‘X10’ connector outputs are
activated for ~ 2 seconds.
When wired to the ‘Lc’ and ‘NO’ contacts—see connection diagram (g. 21), the circuit
will close for ~ 2 seconds in the beginning of opening, while, wired the to the ‘Lc’ and ‘NC’
contacts—see connection diagram (g. 22), the circuit will open for ~ 2 seconds in the
beginning of opening.
Force
This setting is to set up the electric motor force for the gate motion. When the setting is
enabled, an obstacle detected while the gate is closing will cause the gate to stop and the
gate leaves to fully open. In case this happens while the gate is opening, this will cause the
leaves to stop.
The setup is achieved by applying incrementally, steps of 1 unit of force:
— Disabled.
Detection of obstacles is o, while the drive force is maximum.
Default setting.
— minimum value.
— maximum value.
Y
Personnel should be exceptionally careful about the setup. Set up the force to ensure
correct operation of the drive and gate and to exclude the possibility of damage,
harm, and false activation.
