IS-200A
3. Name and Functions of Each Section
3-5
6) Connector
This connector is used to connect the circuit cable. Connect the other end of the
cable to the [PROGRAM MONITOR I/O] connector of the Power Supply.
CAUTION
No settings or changes may be made to any item from the receipt of the start
signal through the end of the weld sequence and turning off the Start signal.
If setting is performed while the start signal is input, the following screen
appears. Turn off the start signal and press [TROUBLE RESET] key 1).
(Note) While the start signal is input, 1) [TROUBLE RESET] key, [TROUBLE
RESET] key on the front panel (see (1) 6)) and the error reset input
terminal of the external I/O (see 6. Interface) do not work. Be sure to turn
off the start signal before resetting an error.
IS -200A IS BUSY OR NOT CONNECTED
Please RESET key in
