4. How to Operate Screens
4-29
Turn off the power supply and turn on it again, or disconnect the MA-627A with
the power supply turned on and connect to the circuit cable again.
When PROGRAM PROTECT is ON, the display of the MENU screen changes.
COPY SETUP DATA, I/O CHECK and RESET TO DEFAULT are not displayed.
On the other screens, the cursor can be moved and the settings can be
checked, but the settings cannot be changed.
<When the PROGRAM PROTECT is OFF>
[MENU]
>POWER SUPPLY STATE COPY SETUP DATA
SCHEDULE MODE SELECT
MONITOR MONITOR MODE
MONITOR SET STEPPER COUNT
I/O CHECK
RESET TO DEFAULT
<When the PROGRAM PROTECT is ON>
[MENU]
>POWER SUPPLY STATE
SCHEDULE MODE SELECT
MONITOR MONITOR MODE
MONITOR SET STEPPER COUNT
(13) OVER WRITE / DOWN LOAD Screen
Usually, the MA-627A is operated as a program unit of the connected model the
moment it is powered on.
In the following cases, however, it takes a few minutes for the MA-627A to be
powered on and become usable due to update process of the contents of memory.
When the device is started for the first time after newly purchasing (a test
program for inspection is stored) or the connected model is changed (See
OVER WRITE screen.)
When the memory rewriting is restarted after cancelled halfway or the battery for
backup is dead (See DOWN LOAD screen. For battery replacement, see the
operation manual for the MA-627A.)
ATTENTION
On the OVER WRITE screen and the DOWN LOAD screen, “ISC-200A” is
displayed as the connected model name, but select YES and press the
[ENTER] key to rewrite the memory.
