9. Specifications
9-1
9. Specifications
(1) Specifications
*: Selectable for every 255 schedule
Welding powe
r
3-phase, 200–240 V AC (50/60 Hz) ±10%
Max. output current
200 A (peak value)
Duty cycle: 4% (at 40°C of ambient temperature)
Number of
schedules
255
Output frequency
2 kHz
Control method *
Primary constant-current effective value control
Secondary constant-current effective value control
Secondary constant-power effective value control
Primary constant-current peak value control
Secondary constant-voltage effective value control
Constant-phase control
Timer setting range
*
SQD / squeeze delay time
SQZ / squeeze time
U1 / upslope 1 time
WE1 / weld 1 time
D1 / downslope 1 time
COOL1 / cooling 1 time
U2 / upslope 2 time
WE2 / weld 2 time
D2 / downslope 2 time
COOL2 / cooling 2 time
U3 / upslope 3 time
WE3 / weld 3 time
D3 / downslope 3 time
HOLD / hold time
OFF / off time (Note 1)
0000–9999 (ms) / 000–999 (CYC)
000–9999 (ms) / 000–999 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–99 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–99 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–50 (CYC)
000–999 (ms) / 00–50 (CYC)
00000–20000 (ms) / 000–999 (CYC)
0 or 0010–9990 (ms) / 00–99 (CYC)
Transformer turns
ratio *
(P/S RATIO)
1.0–199.9
Pulsation setting *
(PULSATION)
01–19
V
alve setting *
(VALVE)
2 valves (VALVE1, VALVE2)
Control gain *
(GAIN)
1–9
Setting range *
(HEAT)
Constant current control
(Note 2)
Constant power control
Constant voltage control
Constant phase control
0.10–4.00 kA
0.20–9.99 kW
0.50–5.00 V
10.0–99.9%
Current monitor *
(CURRENT
LOW/HIGH)
HIGH (upper limit)
LOW (lower limit)
0.00–9.99 kA
0.00–9.99 kA
Powe
r
monitor *
(POWER
LOW/HIGH)
HIGH (upper limit)
LOW (lower limit)
00.00–99.99 kW
00.00–99.99 kW
V
oltage monitor *
(VOLT HIGH/LOW)
HIGH (upper limit)
LOW (lower limit)
0.00–9.99 V
0.00–9.99 V
