IS-200A
4. How to Operate Screens
4-30
OVER WRITE screen
When the connected model is incompatible with the previously stored model
name / program version, “CONNECT IMPOSSIBLE!!” is displayed at the bottom
of the screen as shown below.
Set OVER WRITE to YES with the [+ON] key and press the [ENTER] key to
rewrite the memory.
It takes about 5 minutes to rewrite the memory.
After rewriting, the MA-627A can be used.
CONNECT MEMORY
ISC-200A-M [V00-01A] IS-470B-MA [V00-01A]
ISC-200A-S [V00-01A] TEST [V00-02A]
CONNECT IMPOSSIBLE!! OVER WRITE : YES
DOWN LOAD screen
This screen is for downloading a program from the product connected to the
MA-627A.
To download a program, set DOWN LOAD to YES with the [+ON] key and
press the [ENTER] key.
It takes about 5 minutes to download a program.
After downloading, the MA-627A can be used.
CONNECT MEMORY
ISC-200A-M [V1-01A] BACK UP ERASED
ISC-200A-S [V1-01A]
DOWN LOAD : YES
To Next Page
