IS-200A
4. How to Operate Screens
4-23
 When the no-current error or the overcurrent error occurs, the function
changes depending on the setting of END SIGNAL MODE.
 When END SIGNAL MODE is 0 or 1, welding stops when an error
occurs and does not move to the next schedule. The NG signal is
output and the END signal is not output. The next start signal is not
received until the error reset signal is input.
 When END SIGNAL MODE is 2, welding of the schedule in which
an error occurs stops and moves to the next schedule. The NG
signal and END signal are output after all weldings are completed
and the next start signal is received.
(Note 3) Transferring monitor data and error data in the single-directional
communication mode
(For data strings, see 10. External Communication Function.)
 The monitor data of all schedules are transferred after welding.
Ex. 1) When the schedule is 1 and TRANS SCAN MODE is 1-3
!01001:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 1)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01002:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 2)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01003:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 3)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
 The error data of the schedule having errors is transferred after the
monitor data is sent.
Ex. 2) Current caution (E06) and pulse width caution (E07) for
schedule 1, and voltage caution (E18) and power caution
(E19) for schedule 3 in Ex. 1)
!01001:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 1)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01002:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 2)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01003:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 3)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01001:E06,07[CR][LF] (schedule 1)
!01003:E18,19[CR][LF] (schedule 3)
 The monitor data of the schedule having no error and error data are
transferred if an error occurs when END SIG MODE is 2.
Ex. 3) Non-current error (E05) for schedule 2, and current error (E06)
for schedule 2 in Ex. 1)
!01001:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 1)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01003:m,120,1.20,0.50,00.60,20.0,200,2.00,1.50,03.00,40.0, (schedule 3)
300,2.50,2.00,05.00,50.0,2,0010,5,0100,2222[CR][LF]
!01002:E05[CR][LF] (schedule 2)
!01003:E06[CR][LF] (schedule 3)
e) PAGE UP
When the cursor is at , moving the cursor up will return the display to the
previous screen.
