IS-200A
10. External Communication Function
10-7
Item Contents
Character
String
Range
20 HEAT3
n.nn, 0.10 to 9.99 (kA, kW, V)
nn.n, 10.0 to 99.9 (%)
21 PULSATION nn, 01 to 19
22 GAIN n, 1 to 9
23 VALVE n, 1 to 2
24 TURN RATIO nnn.n, 001.0 to 199.9
25 WELD ON/OF n,
0: OFF
1: ON
26 TRANS# n 1 to 5
(*1) The setting of ms/CYC cannot be changed. You can change it via Screen 05
(SYSTEM data).
(*2) 10-ms increment. The setting in 1ms is omitted.
 Screen 02 (MONITOR SET data)
Specific data in accordance with Schedule No. (Schedule No.: 001 to 255)
Item Contents
Character
String
Range
1 CURRENT HIGH of HEAT1 (upper limit) n.nn, 0.00 to 9.99 (kA)
2 CURRENT LOW of HEAT1 (lower limit) n.nn, 0.00 to 9.99 (kA)
3 VOLT HIGH of HEAT1 (upper limit) n.nn, 0.00 to 9.99 (V)
4 VOLT LOW of HEAT1 (lower limit) n.nn, 0.00 to 9.99 (V)
5 POWER HIGH of HEAT1 (upper limit) n.nn, 0.00 to 9.99 (kW)
6 POWER LOW of HEAT1 (lower limit) n.nn, 0.00 to 9.99 (kW)
7 PULSE HIGH of HEAT1 (upper limit) nnn, 010 to 100 (%)
8 CURRENT HIGH of HEAT2 (upper limit) n.nn, 0.00 to 9.99 (kA)
9 CURRENT LOW of HEAT2 (lower limit) n.nn, 0.00 to 9.99 (kA)
10 VOLT HIGH of HEAT2 (upper limit) n.nn, 0.00 to 9.99 (V)
11 VOLT LOW of HEAT2 (lower limit) n.nn, 0.00 to 9.99 (V)
12 POWER HIGH of HEAT2 (upper limit) n.nn, 0.00 to 9.99 (kW)
13 POWER LOW of HEAT2 (lower limit) n.nn, 0.00 to 9.99 (kW)
14 PULSE HIGH of HEAT2 (upper limit) nnn, 010 to 100 (%)
15 CURRENT HIGH of HEAT3 (upper limit) n.nn, 0.00 to 9.99 (kA)
16 CURRENT LOW of HEAT3 (lower limit) n.nn, 0.00 to 9.99 (kA)
17 VOLT HIGH of HEAT3 (upper limit) n.nn, 0.00 to 9.99 (V)
18 VOLT LOW of HEAT3 (lower limit) n.nn, 0.00 to 9.99 (V)
19 POWER HIGH of HEAT3 (upper limit) n.nn, 0.00 to 9.9 (kW)
20 POWER LOW of HEAT3 (lower limit) n.nn, 0.00 to 9.99 (kW)
21 PULSE HIGH of HEAT3 (upper limit) nnn 010 to 100 (%)
