4.2 How to examples...
This section covers some common tasks that are often performed with an AC power source.
These examples are written in a “How to...” format and provide step by step instructions on
how to set up the AC Source for specific tasks.
4.2.1 Set the Output
Output parameters are Voltage, Frequency and Current Limit.
1. Disable the output by pressing the OUTPUT button. The LED above the button will turn
off.
2. Use the left knob to set the output voltage. Clockwise will increase the output, counter
clockwise will reduce the output. The display above the knob will show the voltage
setting.
3. Use the right knob to set the frequency and current limit. The SELECT button will define
the function of the knob and the display above it. The Frequency or Current LED will turn
on to indicate the function controlled by the right knob.
4. Enable the output by pressing the OUTPUT button.
4.2.2 Slew Output Values
The output parameters can be slewed using the control knobs.
1. Enable the output by pressing the OUTPUT button. The LED above it will turn on.
2. Use the left knob to set the output voltage. Clockwise will increase the output, counter
clockwise will reduce the output. The display above the knob will show the voltage
setting.
3. Use the right knob to set the frequency or current limit. The SELECT button will define
the function of the knob as indicated by the display above it. The LED‟s located above
the display will indicate the selected function.
