Ametek 2003RP - Available Options

2.10 Available Options
2
Option
Description
-AV
Avionics version: 2003RP-AV
115 V
RMS
/ 230 V
RMS
volt ranges
5.9 / 2.9 Amp RMS maximum current per phase
Frequency range limited to 360 Hz minimum.
The unit may be factory set to fixed frequency and single voltage
range. The frequency range and voltage range setting can be
queried over the bus if the –OP1 option is installed.
-HV
Higher Voltage version 2003-HV
156 V
RMS
/ 312 V
RMS
volt ranges
4.3 / 2.1 Amp RMS maximum current per phase
-L22
Locking knobs. Prevents front panel change of voltage and
frequency.
-OP1
Option package 1 includes:
Measurement Functions
Combined IEEE-488 / RS232C interface
Remote Inhibit Input
Function Strobe Output
-RMS
Rack mount slides
CI P/N 211045
General Devices Model C300S-120-B308
The rack mount slide mounting holes centerlines on the side of the power source are 2.92
inches / 74.3 mm above the bottom edge of the front panel.
Note: The 2003RP series models cannot be mounted in a cabinet by just using
the front panel rack ears. They require additional support.
Figure 2-2: Rack Mount Slides (-RMS option) position
2
Additional options may have been made available since this manual revision. Installed options are listed on
the power source‟s type label. A manual addendum may be issued for new options not covered by this
manual.
