Ametek 2003RP User Manual

1 Introduction
This instruction manual contains information on the installation, operation, calibration and
maintenance of the 2003RP AC power source.
1.1 General Description
The 2003RP AC source is a high efficiency, lightweight, three-phase, 2000 VA,
programmable AC power source. In addition to the standard 2003RP model, several options
are available that may change the voltage and frequency ranges of the power source. This
user manual covers the following models:
Model
Voltage ranges
No. of
Outputs
Max.
Current
Frequency range
2003RP
135 V
RMS
270 V
RMS
3
5 A
RMS
2.5 A
RMS
16 Hz – 5000 Hz
2003RP-AV
1
Avionics version
115 V
RMS
230 V
RMS
3
5.9 A
RMS
2.9 A
RMS
360 Hz – 5000 Hz
2003RP-HV
156 V
RMS
312 V
RMS
3
4.3 A
RMS
2.1 A
RMS
16 Hz – 5000 Hz
Table 1-1: Available models
The output voltage terminals for each output phase are isolated from the chassis (earth)
ground. The nominal input can be either 107/115 VAC or 208/230 VAC at 50/60/400 Hz line
frequency.
Simple front panel controls enable the voltage, phase selection, current limit, and frequency
to be changed. An optional RS232C and IEEE 488 interface is available for applications that
require remote control and measurements. Settings are displayed for one output phase at a
time. The selected phase can be toggled between A, B, and C using the phase select key.
1.2 Accessory Equipment/Rack Slides
General Devices Company Model C300S-120-B308 rack slides may be attached to the sides
of the power source using 10-32 X 3/8 flat head screws.
1
2003RP-AV models may be factory configured with a single voltage range and fixed frequency output.
