Parameter
Specification
Frequency
2003RP:
2003RP-HV:
16.0
- 5000 Hz (see Figure 2-1)
Maximum
output voltage av
ailable from 45 Hz and
up. Maximum
voltage derates from 100% at 45 Hz
to 35% at 16 Hz
.
2003RP-
AV:
360.0
- 5000 Hz (see Figure 2-1)
Resolution
:
0.01 Hz from 16.0
0 to 80.00
Hz
0.1 Hz from 80.1 Hz to 8
00.0 Hz
1 Hz from 801 Hz to 500
0 Hz
Accuracy:
0.02% of program
med value
Tem
perature
coefficient:
± 5 ppm per degree Celsius
Stability
:
± 15 ppm per year
Impedance
Steady
State:
(voltage range * 0.
0005) / load current.
Figure 2-1
: Availabl
e RMS Current as functio
n of Output Volta
ge and Freq
uency.
