12 LS User Manual
The frame should be positioned rst and the instructions for set-up and wiring supplied with the frame
followed closely.
Because the mountings protrude from the bottom of the LS, the machine cannot stand on it’s own
until it is tted and secured to the mounting frame.
NOTE: No specic information about mounting an LS Pogo can be issued with the
machine on it’s own because the size and specication of the frame are decided by the
customer’s specic needs.
CAUTION: Suitable lifting equipment should be employed.
The Pogo Rod should be tted last. Secure the LS to the top of the frame as per the instructions sup-
plied with the frame. Insert the rod through the bearing on the lower (xed) crosshead of the LS and
connect to the Bottom Platen. Connect to the Loadcell last.
