Ametek LS1 Series - 9.16 Test Type Configuration; Setting Limit Values; Sample Stiffness Configuration

LS User Manual 41
Limit Hold Sample Initial
10.00 30 Stiffness 100000.0
mm seconds Manual N/mm
Limit Hold Sample Initial
10.00 30 Stiffness 100000.0
mm seconds Auto N/mm
Limit Hold
10.00 0
mm seconds
Speed Set Machine
150 Preload Stiffness
mm/min Values Enabled <
Test Test Set
Mode Type Limit
Tension Limit Values >
9.16 TEST TYPE
Pressing the Test Type Soft Key will allow the test type to be dened.
Press a key to change a parameter
Pressing the > Soft Key will toggle between the display above and the next display.
Press a key to change a parameter
The test mode Soft Key toggles between Tension and Compression.
The Test Type Soft Key toggles between Limit and Cycling. In cycling mode the Set Limit Values
Soft Key changes to Set Cycling values.
Pressing the Set Limit Values Soft Key will allow the values to be set.
Press a key to change a parameter
The limit type, value and unit may be set or changed by pressing the Limit Soft Key. The required
parameters may then be entered.
If either a Hold value is set or if the units of Speed are in load rate units sample stiffness information
will be displayed.
Press a key to change a parameter
Sample Stiffness can be set to Auto (see above) or Manual (see screen below). Sample stiffness is
used when a test is being carried out under load rate control, i.e. when driving at a rate of Newtons
per minute or lbs per inch. The machine speed will have to vary depending on the stiffness of the
sample.
Manual Sample stiffness uses the value entered throughout the test. Auto sample stiffness starts
from an Initial value and throughout the test re-calculates this value.
Press a key to change a parameter
