6.3 THE DISPLAY
The display, which has 4 lines of 40 characters, is used to show or request information. The informa-
tion displayed depends upon the status of the machine but generally, the top line displays a title or
help information for each display. The lower lines are split into 4 blocks, one block above each Soft
Key, to indicate the function of that key.
6.4 “SWITCH-ON” DISPLAY
When rst switched on the display will be blank while the system performs some routine checks.
After a few seconds the display will show information about the machine and the version of the em-
bedded software installed. Similar to the one shown below.
LLOYD INSTRUMENTS LTD
LS Materials Testing Machine
Version TBD
Load Cell 001234 N
This information is displayed for three seconds after which the test selection screen is displayed.
The next display shows that a test called CYCLE_TEST has been dened. The number in brackets
shows the number of sample results currently stored with this test.
Select the required test
CYCLE_TEST (150 Samples)
A total of 600 sample results can be stored across all test set-ups. If the total number of samples cur-
rently stored with all the test set-ups exceeds 500 then the third line will display a warning message.
Select the required test
CYCLE_TEST (501 samples)
Warning: Only space for 99 more samples
As the left and right arrow ( < > ) Soft Keys are pressed, the names of the previously dened tests
will be shown.
When the rst test is displayed, the left arrow will be hidden as shown below.
Select the required test
LIMIT_TEST (150 samples)
When the last test is displayed, and less than 10 set-ups have been dened the display below will be
shown.
