52 LS User Manual
12.3 OVERALL DIMENSIONS LS
A
BC
D
E
LS1 mm in
A Height (standard travel) 1016 40.0
A Height (extended travel) 1301 51.2
B Width (excluding console) 460 18.1
C Depth 557 21.9
D Base Height 108 4.3
E Throat Depth 180 7.1
