46 LS User Manual
Max Load Min Load Max Ext Min Ext
5000 100 250.00 100.00
N N mm mm
Test Pass/Fail Break Peak
Result Checks Pass/Fail Pass/Fail
Units On Limits Limits
Peak Peak Break Break
Load Ext Load Ext
N mm N mm
Test Pass/Fail
Results Checks
Units Off
9.19 TEST RESULTS
Pressing the Test Results Soft Key from the Test Setup Display will allow the test results units and
pass/fail limits to be set.
Press a key to change a parameter
Pressing the Tests Result Units Soft Key allows the units to be set.
Press a key to change a parameter
9.20 PASS/FAIL VALUES
If Pass/Fail is set to On, another two options are available.
Press a key to change a parameter
Pressing either the Break Pass/Fail limits or Peak Pass/Fail Soft Keys will allow the values to be
set.
Break pass/fail values
Press a key to change a parameter
