LS User Manual 31
Sample Stats Reset Suspend
Continue Suspend
Suspend
If the batch questions option is turned on, then the following screen will be displayed. A “batch” being
a series of tests all carried out with the same settings. The “batch questions” are 3 two word ques-
tions which can be set-up at the beginning of a new “batch”
Press a key to change a parameter
OPERATOR BATCH
NAME NUMBER
The information can only be entered when a new batch is started i.e. when sample number 1 is to be
tested. The operator can answer the questions by pressing the Soft Key below each question.
Pressing the Enter key will conrm all the answers to the batch questions and show the pre-test
display.
If the operator is continuing with a previously suspended batch, then the batch questions, and their
answers, will be displayed in a “view only” mode.
OPERATOR DAVE
BATCH NUMBER B21_G
Here the operator will be given the option to Continue with the previously suspended batch or to
Suspend the batch again by pressing the appropriate Soft Keys.
Press GO to test Sample 1
6.00mm x 3.00mm MOULD_32
Ext 10.00mm Load 276N
On the top line of the Pre-test display help information is shown. On the second line, the right hand
side shows the test setup name.
On the third line, Extension and Load are displayed.
To Next Page
