LS User Manual 49
Unexpected reset code XX
Unexpected software reset code XXX
Software reset code 106 (XXXXXX)
These messages indicate that an internal error has caused the system to reset unexpectedly. Please
make a note of the readings and contact LLOYD INSTRUMENTS Technical Support for help.
System Hardware Error
An error has occurred in the internal electronics of the system.
Drive System Error
The motor control system has not been able to maintain adequate control of the motor and has shut
down as a safety precaution. This will usually indicate a fault within the motor drive or extension mea-
surement system.
Accessory Connected/Disconnected
An accessory has been connected or removed while the crosshead is being driven.
Load / Speed / Rating Exceeded
The machine has moved outside the load and speed rating of the machine. Ensure the test being
performed is within the machine’s load and speed rating
Extensometer Range Exceeded
The machine has moved outside the range of the extensometer. Ensure the test being performed is
within the range of the extensometer.
LS1 Error reporting
Small Console Large Console / PC
Error Number Error Message
0 Data Packet Error
1 Motor Drive Fault
2 Upper Limit Switch
3 Lower Limit Switch
4 Safeline Open
5 No Loadcell
6 Splinter Shield Open
7 Cell Overload
8 Safety Overload
9 Frame Overload
10 Grip Overload
11 Print unavailable. Power down and retry
12 Unexpected reset code 01
13 Unexpected reset code 02
14 Unexpected reset code 04
15 Unexpected reset code 08
16 Unexpected reset code 10
17 Unexpected reset code 20
