Dansensor® MAP Mix Provectus EN User Guide 39
P/N 300862-K
11/2019
0xA07E Mix 1 actual
setting
(Read only)
1 unsigned byte
Range 0 to 100%
For a 3-gas mixer this is the mixer setting of %CO
2
For a CO
2
/N
2
mixer this is the mixer setting of %N
2
For a N
2
/O
2
mixer this is the mixer setting of %N
2
For a CO
2
/O
2
mixer this is the mixer setting of %CO
2
0xA07F Mix 2 actual
setting
(Read only)
1 unsigned byte
Range 0 to 100%
For a 3-gas mixer this is the mixer setting of %N
2
For a CO
2
/N
2
mixer this is the mixer setting of %CO
2
For a N
2
/O
2
mixer this is the mixer setting of %O
2
For a CO
2
/O
2
mixer this is the mixer setting of %O
2
0xA080 Mix 3 actual
setting
(Read only)
1 unsigned byte
Range 0 to 100%
Only present in a 3-gas mixer.
This is the mixer setting of %O
2
.
For a 2-gas mixer this register returns zero.
0xA084 Actual Vacuum
buffer pressure
4 byte float
Actual pressure in the vacuum buffer [bar]
0xA06E Vacuum buffer
set pressure
(read only)
4 byte float
Actual set point for the pressure in the vacuum buffer.
Typical 3.0 or 5.0 bars
0xA072 Vacuum buffer
hysteresis
(read only)
4 byte float
Typical 0.3 bar. When buffer pressure reach "Vacuum buffer
set pressure" - "Vacuum buffer hysteresis" the valve is
turned on. When the pressure reaches "Vacuum buffer set
pressure" it is turned off.
0xA076 Vacuum buffer
min on time
(times 100ms)
(read only)
1 byte unsigned
Not used, will always return 0
0xA077 Vacuum buffer
min off time
(times 100ms)
(read only)
1 byte unsigned
Not used, will always return 0
0xA0D6 Output valve
mode
1 byte unsigned
See also write 0x0066
0 = OFF, mixer is stopped
1 = Running (Auto). Normal operation mode.
Location Register read Encoding
