Tools, Equipment, Hardware, and Supplies
Required for Installation
All connections are made using U.S. standard size connectors.
To install the ta7000R you need the following tools, equipment, hardware, and
supplies:
Open end wrenches 1/4", 5/16", 3/8", 5/8", 3/4"
Phillips head screwdriver
Allen keys 1/16", 7/64", 9/64"
Flow Meter (Digital in the SCCM range)
Mirror
Magnet
Detergent-based leak detector Snoop® or another suitable leak detection
agent is permissible.
Support gases
Suggested Hardware for Gas Connections
UHP Regulators for Carrier/Sample and Support Gases:
Dual-stage stainless steel, 0–150 PSIG outlet with gauges and 1/16-inch VICI female ttings.
UHP Regulator, Calibration Gas:
One (1), dual-stage stainless steel, 0–150 PSIG outlet with gauges and 1/16-inch VICI ttings.
Adapter, 1/16-inch VICI to 1/4-inch VCR:
Four (4), required for gas connections via 1/16-inch tubing umbilical at regulators,
AMETEK Part No. 220-091.
Nut, 1/4-inch VCR Gland, Male:
Four (4), required for use with VICI–VCR adapters at regulators.
Nut and ferrule, 1/8-inch VICI:
One (1), required for use in connecting the Actuator gas.
Gasket, 1/4-inch VCR, Nickel:
Eight (8), required for use with VICI-VCR adapters.
Tubing, 1/16-inch OD x 0.03-inch ID, Stainless Steel:
Four (4), approximately 72" lengths for gas supply umbilical.
Tubing, 1/8-inch OD, for Pneumatic Line (Actuator gas):
One (1), approximately 72" length for gas supply umbilical.
