PN T900-013, Rev A
Working From the Main Menu
After warm-up has completed successfully the Main Menu screen will be
displayed. The Main Menu is a set of primary choices leading to other menu
options.
The selections from the Main Menu include:
Run
Select this to initiate sample analysis according to event program.
Cool
Select this to reverse the automatic Warm-up cycle and return the instru-
ment to a neutral state.
Calib
Select this to initiate the Calibration gas analysis function (spanning).
Blank
Select this to initiate Zero gas analysis (blanking).
Page
Select this to view the rst of three (3) Information screens, which display
information about the ta7000R, errors, and analytical Trends, and allow you
to congure certain ta7000R settings.
Figure 3-3.
Main Menu screen.
CO
=
H
2
=
Idle Mode
12:34:25
Run Cool Calib Blank Page
3-4 | ta7000R Gas Purity Monitor
