PN T900-013, Rev A
Working From the Calibration Screen
From the Temperatures & Status screen press the Page key to view the Cali-
bration screen, which displays information about the most recent calibration
run. From this screen you can also congure Auto-Calibration parameters.
Name
This is the gas species to be measured.
Conc.
This is the cylinder concentration (or blend) of the Calibration gas con-
nected to the instrument.
Area
This is the area of the last analysis run for each gas type.
Rfactor
This is the Response Factor created by the most recent (or previous) calibra-
tion cycle. Rfactor is used to generate the area.
RT
This is the Retention Time, which is the time point of the peak from the
start of the most recent analysis run.
Conc. Factor
This is a value that is preset at the factory. This number represents the
internal gas blender ratio.
Figure 3-6.
Calibration screen.
Calibration
Idle Mode 12:34:25
Edit Page
Name Conc. Area Rfactor RT
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
H2
CO
8100 1346165
7500 11737367
*
Conc. Factor 200
Cal Time 00:00
Cal Purge 1 Min
Interval None
Cal Tol 10%
3-8 | ta7000R Gas Purity Monitor
