PN T900-013, Rev A
Sample/Carrier Gas Supplies
Specication Description
Inlet Fitting 1/4-inch male face seal tting*
Inlet Pressure Range 4.8–6.1 BAR (70–90 PSIG)
Inlet Pressure Stability ±2 %, UHP regulator required
Vent (Return) Pressure Atmospheric pressure vent is optimal, ±0.5 PSIG maximum
Flow Rate 300 cc/minute minimum, sample bypass at 50 cc/minute
Temperature 16 °C to 38 °C (60 °F to 100 °F), optimum when maintained ±2 °C
Maximum Impurity Levels 200 PPB Moisture, CO
2
, Hydrocarbons
* 1/4-inch face seal x 1/16-inch adapter ttings are available from ΑΜΕΤΕΚ.
Gas Ports
Specication Description
Carrier/Sample Inlet 1/4-inch VCR compatible
Aux (Calibration) 1/16-inch VICI compression
Sample Outlet 1/16-inch VICI compression
Actuator Gas 1/8-inch VICI compression
Actuator Gas
Specication Description
Inlet Fitting 1/8-inch VICI compression tting
Inlet Pressure Range 4.8–10.2 BAR (70–150 PSIG)
Gas Type Inerts (Nitrogen, Argon, Helium), 7 nines or better or CDA,
dewpoint < -65 °C
Gas Type
(for ta7000R-O
2
only)
Inerts (Nitrogen, Argon, Helium), 7 nines or better
Calibration Gas
Specication Description
Inlet Fitting 1/16-inch VICI compression tting
Cylinder Concentration 5–10 PPM H
2
, CO, balance Nitrogen
Cylinder Volume 100 cubic feet minimum (2800 L)
Supply Pressure 5.4–6.1 BAR (80–90 PSIG)
Consumption Approximately 1.0 L per calibration (4–8 L/month), automatic
shut-o between calibration.
5-2 | ta7000R Gas Purity Monitor
