3.6. Lubrication and Maintenance Operations
3.6.3. Inspect the engine belt
Make visual belt inspection, monitor any of its damage. •
Cracks perpendicular to the belt width are not considered
a damage.
3.6.4. Crankcase breather
Check crankcase breather pipe so it is not clogged due to •
any deposits, fragments, chips, or in winter frozen with ice.
When longitudinal cracks occur on the
belt, or belt edges are shattered, or ex-
tracted parts of material, then the belt
must be replaced.
When running the Machine during low
temperature period or under low tem-
perature conditions, make the inspec-
tions in shorter intervals.
