Ammann AV 70 X - Fuel Level Check

104 AV 70 X
400165
1
2
400166
3
478320
h
400111A
3.6. Lubrication and Maintenance Operations
3.6.7. Fuel level check
Check the amount of fuel on LH cluster signalled by LEDs, •
and in case of lack of fuel, please replenish.
Minimal amount of fuel is signalled by red LED ickering.•
Do NOT use up fully the tank. When used
up fully the entire fuel system must then
be deaerated, which is rather hard and
demanding.
Use solely a clean recommended fuel per
Section 3.2.2.
NEVER replenish fuel in conned space.
Fuel must NOT be spilled.
Clean tank ller cap (1) and ller neck (2).•
Unlock tank ller cap lock, turn the ller cap and remove it.•
Rell the tank up to the bottom edge of ller neck via the •
strainer (3).
Note
Fuel tank capacity is 110 l (29 gal US). Fuel tank will last ca 14
hours of the Machine operation.
NO smoking and no use of open ame
when at work.
Do NOT rell fuel while engine is
running.
