Ammann AV 70 X - Machine Lubrication

117AV 70 X
400192
400193
400191
MAINTENANCE MANUAL
Main bearing 4x
Linear hydraulic motors for steering
Pins 6x
3.6.17. Machine lubrication
• Takeothecapsonthegreasingnipples.
• Stepbystep,putonthegreasingnippleofhigh-pressurepressandlubricatetilltheoldgreasestartspouringout.
• Reinstallthegreasingnipplecaps.
Steering joint
Upper bearings 2 x
Lower bearings 2 x
Use only the recommended lube greases, refer to Section 3.2.5.
