Ammann AV 70 X - Machine Description

39AV 70 X
12
13
21
5
8
19
1
2
17
14
15
4
3
20
6
7
9
400625
10
11
16
18
20
21
21
21
OPERATION MANUAL
2.5. Machine Description
1 - Front frame
2 - Rear frame
3 - Front drum
4 - Rear drum
5 - Engine
6 - Drum travel hydroelectric generator
7 - Drum vibration hydroelectric generator
8 - Travel hydraulic motor
9 - Vibration hydraulic motor
10 - Steering joint
11 - Hydraulics tank
12 - Fuel tank
13 - Sprinkling tank
14 - Cabin with integrated ROPS
15 - Driver’s control stand
16 - Battery
17 - Combined engine and hydraulic oil cooler
18 - Air lter
19 - Exhaust pipe
20 - Sprinkling jets
21 - Drum scrapers
