77AV 70 X
OPERATION MANUAL
2.7.7. Sprinkling
It is used to sprinkle the Machine drums.
Switch ON one of two sprinkling pumps via sprinkling pumps selector switch (11).
Indicator lamp on cluster (26) will signal the function of switching ON the sprinkling pump.
Green LEDs signal water level in the tank, red LED ashes when emptied to min.
Using the potentiometer of the watering cycle interval (10), set the watering intensity within the range of MIN/MAX.
The watering intensity depends on the driving speed; the standing machine performs watering only if the potentiometer (10) is set
to MAX.
Using the watering button (9), it is possible to switch on the additional watering of drums, e.g. before driving on a compacted bitumen
surface.
Check water level in the tank during Machine operation.
We recommend to alter the pumps following 100 motohours in order to ensure their uniform wear.
