3.6. Lubrication and Maintenance Operations
HINGED SCRAPERS (optional)
The Machine is tted with four hinged (tilting) scrapers.•
Position the scrapers:
In position (1) the scraper is set in transport position.•
In position (2) the scraper is set in working position.•
When in working position, the scraper blade (3) is pressed •
against the drum body (4) by means of gas struts (4).
Replace the blade:
When the blade becomes excessively worn, please lift o •
the scraper, remove the bolts (5) and take o the blade (3)
along with the strip (6).
Proceed in reverse steps to reinstall a new blade.•
At the same time always check the proper function of the •
gas struts (4).
Only when the gas struts work properly
and the worn scraper blades are replaced
in time, this will provide you with perfect
drum cleaning!
