2.6. Machine basic functions control
Control tie rod for heating valve (39)
It is used to switch ON the cabin heating.
Make continuous control from MIN position (valve closed) to
MAX position (valve fully open) for the amount of liquid owing
to the heating body.
Adjust the heating valve before driving!
Hand pump control lever (40)
It is used to control the hand pump when lifting or letting down
the bonnet.
Location in case of the machine with a ROPS cab
The Machine shall be equipped with
rst-aid box!
Location in case of the machine with a ROPS platform and rail
First-aid box stowage place (41)
